XF103 – FINAL PUMP ø36.5 FEMALE FLANGE
| Group 1 |
| Final Pumps |
Açıklama
| Technical data table | |||||
| TYPE | Displacement | Max. Pressure | CODE | ||
| cm3/rev | P1 bar | P3 bar | Left rotation | Right rotation | |
| X1F-2/0.9 | 1 | 240 | 280 | X1F1681TIIA | X1F1682TIIA |
| X1F-2/1.2 | 1 | 250 | 290 | X1F1781TIIA | X1F1782TIIA |
| X1F-2/1.7 | 2 | 250 | 290 | X1F1881TIIA | X1F1882TIIA |
| X1F-2/2.2 | 2 | 250 | 290 | X1F2081TIIA | X1F2082TIIA |
| X1F-2/2.6 | 3 | 250 | 300 | X1F2181TIIA | X1F2182TIIA |
| X1F-2/3.2 | 3 | 250 | 300 | X1F2381TIIA | X1F2382TIIA |
| X1F-2/3.8 | 4 | 250 | 300 | X1F2581TIIA | X1F2582TIIA |
| X1F-2/4.3 | 4 | 250 | 300 | X1F2781TIIA | X1F2782TIIA |
| X1F-2/4.9 | 5 | 250 | 300 | X1F2981TIIA | X1F2982TIIA |
| X1F-2/5.9 | 6 | 250 | 300 | X1F3181TIIA | X1F3182TIIA |
| X1F-2/6.5 | 7 | 250 | 300 | X1F3281TIIA | X1F3282TIIA |
| X1F-2/7.8 | 8 | 220 | 260 | X1F3481TIIA | X1F3482TIIA |
| X1F-2/9.8 | 10 | 190 | 230 | X1F3681TIIA | X1F3682TIIA |
P1) Max. working pressure – P3) Max. peak pressure
