XI001 – STANDARD INTERMEDIATE PUMP ø22 FEMALE FLANGE
| Group 0 |
| Intermediary Pumps |
Açıklama
Teknik Veri Tablosu xi001-1.Pdf
| Technical data table | |||||
| TYPE | Displacement | Max. Pressure | CODE | ||
| cm3/rev | P1 bar | P3 bar | Left rotation | Right rotation | |
| X0I-0/0.17 | 0 | 220 | 260 | X0I121MBBA | X0I122MBBA |
| X0I-0/0.25 | 0 | 220 | 260 | X0I221MBBA | X0I222MBBA |
| X0I-0/0.45 | 0 | 220 | 280 | X0I421MBBA | X0I422MBBA |
| X0I-0/0.57 | 1 | 220 | 280 | X0I521MBBA | X0I522MBBA |
| X0I-0/0.76 | 1 | 220 | 280 | X0I621MBBA | X0I622MBBA |
| X0I-0/0.98 | 1 | 220 | 280 | X0I721MBBA | X0I722MBBA |
| X0I-0/1.27 | 1 | 220 | 280 | X0I921MBBA | X0I922MBBA |
| X0I-0/1.52 | 1 | 220 | 280 | X0I1121MBBA | X0I1122MBBA |
| X0I-0/2.30 | 2 | 190 | 210 | X0I1321MBBA | X0I1322MBBA |
P1) Max. working pressure – P3) Max. peak pressure
