XT001 – STANDARD PRIMARY PUMP ø22 FLANGE
XT001 – STANDARD PRIMARY PUMP ø22 FLANGE
Ürünlere dön
XT017 – HY PRIMARY PUMP ø22 BODY-SHAPED FLANGE
XT017 – HY PRIMARY PUMP ø22 BODY-SHAPED FLANGE
XT012 - BH PRIMARY PUMP ø22 BODY-SHAPED FLANGE - Görsel 1
Büyütmek için tıklayın
VIVOLO

XT012 – BH PRIMARY PUMP ø22 BODY-SHAPED FLANGE

Group 0
Primary Pumps
Kategoriler: Etiketler:
Açıklama

Teknik Veri Tablosu xt012-1.Pdf



Technical data table
TYPEDisplacementMax. PressureCODE
cm3/revP1 barP3 barLeft rotationRight rotation
X0T/0.170220260X0T111BBBAX0T112BBBA
X0T/0.250220260X0T211BBBAX0T212BBBA
X0T/0.450220280X0T411BBBAX0T412BBBA
X0T/0.571220280X0T511BBBAX0T512BBBA
X0T/0.761220280X0T611BBBAX0T612BBBA
X0T/0.981220280X0T711BBBAX0T712BBBA
X0T/1.271220280X0T911BBBAX0T912BBBA
X0T/1.521220280X0T1111BBBAX0T1112BBBA
X0T/2.302190210X0T1311BBBAX0T1312BBBA

P1) Max. working pressure – P3) Max. peak pressure
