XT219 – ‘SAE A’ PRIMARY PUMP ø82.5 FLANGE
| Group 2 |
| Primary Pumps |
Açıklama
| Technical data table | |||||
| TYPE | Displacement | Max. Pressure | CODE | ||
| cm3/rev | P1 bar | P3 bar | Left rotation | Right rotation | |
| X2T/04 | 4 | 260 | 300 | X2T4151ISRA | X2T4152ISRA |
| X2T/06 | 6 | 260 | 300 | X2T4351ISRA | X2T4352ISRA |
| X2T/09 | 8 | 260 | 300 | X2T4551ISRA | X2T4552ISRA |
| X2T/11 | 11 | 260 | 300 | X2T4751ISRA | X2T4752ISRA |
| X2T/14 | 14 | 250 | 290 | X2T4951ISRA | X2T4952ISRA |
| X2T/17 | 17 | 230 | 270 | X2T5151ISRA | X2T5152ISRA |
| X2T/19 | 19 | 210 | 250 | X2T5351ISRA | X2T5352ISRA |
| X2T/22 | 23 | 200 | 240 | X2T5551ISRA | X2T5552ISRA |
| X2T/26 | 26 | 170 | 210 | X2T5751ISRA | X2T5752ISRA |
| X2T/30 | 30 | 160 | 200 | X2T5951ISSA | X2T5952ISSA |
| X2T/34 | 34 | 150 | 190 | X2T6151ISSA | X2T6152ISSA |
| X2T/40 | 40 | 140 | 180 | X2T6351ISSA | X2T6352ISSA |
P1) Max. working pressure – P3) Max. peak pressure
